Handheld Trace Explosive Detector MatriXcope MTC-EX6700XPRO
Portable handheld trace explosive detector with 0.05 ng TNT sensitivity. Detects over 30 explosive substances using advanced fluorescence technology for airports, customs, military, and security screening.
Product Documents
Overview of Handheld Trace Explosive Detector MatriXcope MTC-EX6700XPRO
The MatriXcope MTC-EX6700XPRO Handheld Trace Explosive Detector is a next-generation portable security inspection device designed for fast and accurate detection of trace explosive particles and vapor. Utilizing Amplified Fluorescent Polymer Quenching Sensor technology, the system delivers outstanding sensitivity, rapid response, and reliable performance for security screening in airports, border checkpoints, military facilities, government buildings, public transportation, and critical infrastructure.
Designed for demanding field operations, the MTC-EX6700XPRO combines lightweight portability, rugged construction, and intelligent automatic calibration to provide security personnel with a dependable solution for explosive trace detection.
Key Features of MTC-EX6700XPRO
- High-sensitivity detection of trace explosive residues
- Detects both particle and vapor samples
- TNT detection limit as low as 0.05 ng
- Identifies more than 30 types of military, commercial, and homemade explosives
- Advanced Amplified Fluorescent Polymer Quenching Sensor
- Fast analysis in ≤5 seconds
- Cold start in ≤10 seconds
- Automatic calibration for consistent performance
- Low false alarm rate (≤1%)
- No radioactive source required
- Visual, audible, and vibration alarms
- Lightweight ergonomic handheld design
- Rugged ABS polycarbonate housing
- IP53 protection for field environments
- Stores over 100,000 inspection records
Applications
The MatriXcope MTC-EX6700XPRO is ideal for:
- Airport security screening
- Customs and border control
- Military and defense operations
- Police and law enforcement
- Government facilities
- Critical infrastructure protection
- Ports and logistics centers
- Railway and metro security
- Public event security
- VIP protection missions
- Mail and parcel inspection
- Industrial security inspections
Advanced Detection Technology
Powered by Amplified Fluorescent Polymer Quenching Sensor technology, the MTC-EX6700XPRO delivers exceptional sensitivity while eliminating the need for radioactive sources. The detector analyzes both particulate and vapor samples, enabling rapid identification of explosive residues with minimal operator training.
Its intelligent automatic calibration maintains stable performance and measurement accuracy throughout continuous operation.
Why Choose MatriXcope MTC-EX6700XPRO?
The MatriXcope MTC-EX6700XPRO combines high sensitivity, rapid detection, and exceptional portability in a compact handheld platform. With fast startup, automatic calibration, extended battery life, and the ability to detect over 30 explosive substances, it provides security professionals with a reliable and efficient solution for trace explosive detection in both routine screening and high-risk security operations.
| Technical Specs | |
| Technology | Amplified Fluorescent Polymer Quenching Sensor |
| Analysis time | ≤5s |
| Start-up time | ≤10s |
| Sampling method | Particle and Vapor |
| Detection Sensitivity | Particulate: TNT LOD ≤0.05ng |
| Vapor:10⁻¹⁴ g/cm³ | |
| Operating TEMP | – 20 ℃ ~ 55 ℃ |
| False alarm rate | ≤ 1% |
| Power Consumption | 7.5W |
| Rated voltage | 7.4V |
| Rated Capacity | 65.5Wh |
| Rated Energy | 8850mAh |
| Display Screen | 3″TFT Color display Screen |
| Com Port | USB2.0 |
| Data Storage | ≥100000pieces of record |
| Battery | Two Li-ion Rechargeable Battery |
| Battery Working Time | Single battery time up to 8 hours |
| Battery Charging Time | ≦ 3.5hours |
| Alarming method | Visual / Audible / Vibration |
| Dimensions | 300mm × 106mm × 71mm |
| Weight | ≦ 1.05kg including battery |
| Protection Level | IP53 |
| Substances detected | Military, Commercial, and Homemade Explosives including: TNT, DNT, MNT, Picric Acid, RDX, PETN, TATP, NG, Tetryl, HMX, C4, NA, AN, Black Powder, and others. |
