140KW Handheld Backscatter X-ray Imaging System MatriXcope MTC-HBX8000
Product Documents
Overview of 140KW Handheld Backscatter X-ray Imaging System MatriXcope MTC-HBX8000
The MTC-HBX8000 handheld backscatter X-ray imager is a device that uses X-ray backscatter technology to conduct imaging and detection
of the internal structure of the inspected objects. It has strong penetration capabilities and can perform high-sensitivity, rapid, non-destructive imaging and inspection without contact. It can efficiently detect suspicious items such as explosives, drugs, controlled knives, pistols, and
smuggled goods, which are prohibited and dangerous items. With an integrated design, it is easy to carry and can effectively meet the inspection requirements for various tasks such as security checks, bomb detection, drug control, and confidentiality. It can also be widely applied in places such as customs investigation, borders, ports, and important gatherings.
| PHYSICAL SPECIFICATIONS | |
| Weight | ≤5.6kg |
| Size | 288 * 185 * 246.7 mm (including handle) |
| Penetrating ability | It can penetrate homogeneous steel plates with a thickness of no more than 5mm, and can display organic substances such as plastic blocks in a high-contrast form. |
| Tube voltage | 140kV/10W |
| Detection capability | Explosives and improvised explosive devices, drugs, liquids, organic substances |
| Scanning speed | ≥15cm/s |
| Image method | Real-time imaging |
| Radiation dose | Directly behind the equipment, at a distance of 5 cm from it, the surrounding dose equivalent rate is ≤ 0.2 μSv/h |
| Display screen | 8-inch LCD color touch screen, with image resolution of 1920*1208-inch LCD color touch screen, with image resolution of 1920*120 |
| Maximum scanning time | 30s |
| Working environment | Temperature: 0 – 40℃,
Humidity: ≤ 93%RH |
| Battery life duration | ≥4h |
Outstanding advantages of 140KW Handheld Backscatter X-ray Imaging System MatriXcope MTC-HBX8000
| PHYSICAL SPECIFICATIONS | |
| Weight | ≤5.6kg |
| Size | 288 * 185 * 246.7 mm (including handle) |
| Penetrating ability | It can penetrate homogeneous steel plates with a thickness of no more than 5mm, and can display organic substances such as plastic blocks in a high-contrast form. |
| Tube voltage | 140kV/10W |
| Detection capability | Explosives and improvised explosive devices, drugs, liquids, organic substances |
| Scanning speed | ≥15cm/s |
| Image method | Real-time imaging |
| Radiation dose | Directly behind the equipment, at a distance of 5 cm from it, the surrounding dose equivalent rate is ≤ 0.2 μSv/h |
| Display screen | 8-inch LCD color touch screen, with image resolution of 1920*1208-inch LCD color touch screen, with image resolution of 1920*120 |
| Maximum scanning time | 30s |
| Working environment | Temperature: 0 – 40℃,
Humidity: ≤ 93%RH |
| Battery life duration | ≥4h |
