Luggage Scanning X-ray Machine MatriXcope MTC-XR108D
The MatriXcope MTC-XR108D baggage x-ray machine is designed to screen baggage, mail and parcels at the entrance of sensitive areas, ensuring a high level of safety.
Product Documents
Downloads
Outstanding advantages of the MatriXcope MTC-XR108D luggage scanning xray machine
The MatriXcope MTC-XR108D baggage x-ray machine is designed to screen baggage, mail and parcels at the entrance of sensitive areas, ensuring a high level of safety. The system complies with the highest industry quality standards to ensure maximum safety while using high reliability.
- Dual view technology with images from two angles
- Radiation safe
- High resolution, high penetration and good image quality
- Multilingual operation
- Automatic built in test and self diagnosis
- High load-bearing capacity
- Threat alert and material classification
- Energy saving design
- One key turn off with patent
- Drugs and explosives detection
Contact to order X-ray Baggage scanner MatriXcope MTC-XR108D
In addition to providing baggage scanners, MatriXcope also provides other comprehensive security products such as metal detector systems, supermarket security magnetic gates, access control gates… to learn more useful products than you. You can visit the website: https://matrixcope.com/ to track suitable equipment.
| Physical Specifications | |
| Tunnel size | 1005(W)*802(H) mm |
| Unit weight | 1200 kg |
| Unit size | 3200(L)*1728(W)*1648(H) mm |
| Gross weight | 1400 kg |
| Packing size | #1: 265*215*187cm
#2: 120*65*100cm |
| General Specifications | |
| Conveyor Speed | 0.4 m/s forward or backward |
| Conveyor height | 301 mm |
| Conveyor capacity | 200 kg |
| Frame design | 304 stainless steel, 2-5 mm cold rolled plate and square steel, double-layer staggered lead impregnated safety curtain |
| X ray dose/inspection | ≤4.8μSv |
| X ray leakage | ≤1μSv/h at any point 5 cm outside the external surface. FDA standard is ≤5μSv/h |
| Steel penetration | 41 mm guaranteed |
| Wire Resolution | Horizontal AWG38 / Vertical AWG36 guaranteed |
| Penetration Resolution | AWG30 guaranteed |
| Spatial resolution | 1.3mm Horizontal, 1.3mm Vertical
max. 1.5KW |
| Noise | <60 dB |
| Film Safety | Guarantee ASA/ISO1600 Film |
| Imaging System | |
| Detector | 3840 channels in two L-Shaped Arrays |
| Image processing | Color / black and white imaging, local enhancement, high penetration, low penetration, super enhancement, organic stripping, inorganic stripping, reverse color, brightening, darkening, gray level change/variable contrast, continuously zoom maximum 64x, pseudo color imaging, organics enhancement, suspicious item alarm and notation, edge enhancement imaging, etc. |
| Explosives & Narcotics Detection | Suspicious organics highlight(atomic number Zeff=7,8,9) |
| Suspecious Alarm | Alarm and box line the suspicious objects including hard to penetrate material, explosives and drugs |
| Image pullback | 30 images |
| Image Archive | Up to 50,000 images stored automatically, enable transferring to USB disk, and converting to JPG, BMP and other formats |
| Computer and other | |
| Monitor | Two 21.5-inch LCD monitors, 1920*1080 |
| Console | One |
| CPU | Intel (R) i3 (R) 3.3GHz |
| RAM | 4GB |
| Hard Disk | 1T |
| Keyboard | Special designed |
| Platform | Windows 10 |
| Electric roller | Three-phase |
| Operating Environment | |
| Ops temperature/Humidity | 5oC-40oC 0%-90%(non-condensing) |
| Storage Temperature/Humidity | -20oC to 60oC 10%-90%(non-condensing) |
| Operation Power | 220V(+10% ~ -15%) 50±3Hz
Options: 110-120V, 230-240V, 60Hz |
| COMPLIANCE | |
| International | * ISO19001 ; ISO14001 ; ISO27001 ; OHSMS18001 ;
* CE , ROHS, FCC, REACH * USA, FDA |
